LineaFold 4710
Slim Fold Slide Thermal System
Our Minimal Pivot Slide Systems share the same profile platform as out minimal Bi-fold systems. The main difference is the hardware set. The main advantage of Pivot Sliding over the Bi-fold is the ease of operation and the sash width. Minimal Pivot slide systems can easily reach a sash width of 2 meters. The position of the pivot usually ranges from 1/3 to 1/2 of the sash width. Slim Pivot slide systems typically reach a height of 4 meter that can be extended to 5 meters with suitable reinforcement. Electrical Minimal Pivot Slide systems are available with clusters up to 6 sashes. A set of two facing cluster can reach a total width of 24meters. Minimal Pivot slide doors are available with tracks as low as 43mm in step and fully submerged configurations. Infinity floor and infinity ceiling options are also available. Our Minimal Pivot Slide systems are among the slimmest in the world with a sash profile as low as 27mm (68mm Combined mullion).
| Technical characteristics | |
|---|---|
| Bottom track height | 60 / 76 mm |
| Floor step | 0 / 12 / 48 / 60 mm |
| Frame Height, Horizontal Top | 67 / 84 mm |
| Frame Height, Vertical | 57 mm |
| Frame Width | 60 mm |
| Floor Typology | Step, Submerged |
| Riding Typology | Bottom Rolling |
| Sliding / Alignment rollers | Stainless Steel |
| Sash Height, Vertical | 39 mm |
| Sash Height, Horizontal | 39 mm |
| Sash Width | 60 mm |
| Centre Mullion Height | 92 mm |
| Max. Weight per Sash | 300 Kg |
| Max. Sash Width | 2000 |
| Max. Sash Height | 4000 |
| Opening type | Pivot Slide |
| Glazing Width Possibilities | 32/45mm |
| Maximum Locking Points | 5 |
| Sealing Type | 4 Gaskets |
| Performances | |
|---|---|
| Fabrication Thermal Transmittance EN ISO 10077-2 (Uw) | ≥1.0 W/(m2K) |
